【收藏】第12版美标《IFI紧固件标准手册》（2024版）目录大全

      美国工业紧固件协会（Industrial Fasteners Institute，简称IFI）宣布推出第12版《IFI紧固件标准手册》（2024版）。

      《IFI紧固件标准手册》作为行业资源，汇编了最常用的英寸制紧固件和非ISO公制紧固件标准，汇集ASTM、ASME、SAE和IFI最受欢迎的紧固件标准。除了书中包含的96个标准（其中30个是更新版本），第12版《IFI紧固件标准手册》还新增了IFI 171标准，涵盖了钢结构行业中螺栓、螺柱和螺母装配的螺纹尺寸。

      第12版《IFI紧固件标准手册》体现了美国83年的紧固件标准发展历程。自1941年第1版出版以来，该手册已销往世界各地，成为主要制造和建筑行业人士的常用工具书，是各行业涉及机械连接的设计师、制造工程师和经理的必备资源。

目录 TABLE OF CONTENTS

　　 THREAD SECTION

　　 ASME B1.1-2023 Unified Inch Screw Threads (UN and UNR Thread Form)

　　 ASME B1.2-2024 Gages and Gaging for Unified Inch Screw Threads

　　ASME B1.3-2007(R2022) Screw Thread Gaging Systems for Acceptability: Inch and Metric Screw Threads (UN, UNR, UNJ, M, and MJ)

　　 IFI-301-2008 (R2013) Gage Calibration Requirements and Procedures for Thread Gages

　　IFI-171-2022 Thread Dimensions, Sizes 1-5/8 – 5-1/2 and 1-7/8 – 5 UNS, for Assembly of Bolts, Studs and Nuts, in the Steel Construction Industry

　　BOLTS, STUDS AND THREADED ROD SECTION

　　DIMENSIONS

　　ASME B18.2.1-2012 (R2021) Square, Hex, Heavy Hex, and Askew Head Bolts and Hex, Heavy Hex, Hex Flange, Lobed Head, and Lag Screws

　　ASME B18.5-2012 (R2023) Round Head Bolts

　　ASME B18.9-2012 (R2017) Plow Bolts

　　ASME B18.10- 2006(R2021) Track Bolts and Nuts

　　ASME B18.31.2-2014 (R2019) Continuous Thread, Flange (Stud Bolt), and Double-End Studs

　　ASME B18.31.3-2014 (R2019) Threaded Rods

　　ASME B18.31.5-2011 (R2021) Bent Bolts (Inch Series)

　　IFI -111-2014 Hex Flange Screws

　　IFI-115-2014 Flange 12-Point Screws

　　IFI-148-2002 (R2013) Threaded Projection Weld Studs

　　IFI -199-2014 Tap Bolts (Inch Series)

　　 MATERIAL AND PHYSICAL

　　SAE J429-2014 Mechanical and Material Requirements for Externally Threaded Fasteners

　　ASTM A193/A193M-2023 Alloy Steel and Stainless Steel Bolting Materials for High Temperature Service

　　ASTM A307-2021 Carbon Steel Externally Threaded Standard Fasteners

　　ASTM A320/A320M-2022a Alloy Steel Bolting Materials for Low Temperature Service

　　ASTM A354-2017e2 Quenched and Tempered Alloy Steel Bolts, Studs, and Other Externally Threaded Fasteners

　　ASTM A394-2008 (R2024) Steel Transmission Tower Bolts, Zinc Coated and Bare

　　ASTM A449-2014 (R2020) Hex Cap Screw, Bolts and Studs, Steel, Heat Treated, 120/105/90 ksi Minimum Tensile Strength, General Use

　　ASTM A540/A540M-2015 (R2021) Alloy-Steel Bolting for Special Applications

　　ASTM A962/A962M-2023a Common Requirements For Bolting Intended For Use At Any Temperature From Cryogenic To The Creep Range

　　ASTM A1082/A1082M-2016 (R2021) High Strength Precipitation Hardening and Duplex Stainless Steel Bolting for Special Purpose Applications

　　ASTM F468-2023 Nonferrous Bolts, Hex Cap Screws, and Studs for General Use

　　ASTM F593-2022 Stainless Steel Bolts, Hex Cap Screws, and Studs

　　ASTM F901-2020 Aluminum Transmission Tower Bolts and Nuts

　　ASTM F1554-2020 Anchor Bolts, Steel, 36, 55 and 105-ksi Yield Strength

　　SOCKET SECTION

　　DIMENSIONS

　　ASME B18.3-2012 Socket Cap, Shoulder, Set Screws, and Hex Keys

　　MATERIAL AND PHYSICAL

　　ASTM A574-2021 Alloy Steel Socket-Head Cap Screws

　　ASTM F835-2023 Alloy Steel Socket Button and Flat Countersunk Head Cap Screws

　　ASTM F837-2020 Stainless Steel Socket Head Cap Screws

　　ASTM F879-2023 Stainless Steel Socket Button and Flat Countersunk Head Cap Screws

　　ASTM F880-2012 (R2017) Stainless Steel Socket, Square Head, and Slotted Headless-Set Screws

　　ASTM F912-2011 (R2017) Alloy Steel Socket Set Screws

　　STRUCTURAL FASTENER SECTION

　　DIMENSIONS

　　ASME B18.2.6-2019 Fasteners for Use in Structural Applications

　　MATERIAL AND PHYSICAL

　　ASTM F959/F959M-2017a (R2023) Compressible-Washer-Type Direct Tension Indicators for Use with Structural Fasteners, Inch and Metric Series

　　ASTM F3125/F3125M-2023 High Strength Structural Bolts and Assemblies, Steel and Alloy Steel, Heat Treated, Inch Dimensions 120 ksi and 150 ksi Minimum Tensile Strength, and Metric Dimensions 830 MPa and 1040 MPa Minimum Tensile Strength

　　ASTM F3148-2017a High Strength Structural Bolt Assemblies, Steel and Alloy Steel, Heat Treated, 144ksi Minumum Tensile Strength, Inch Dimensions

　　NUT SECTION

　　DIMENSIONS

　　ASME B18.2.2-2022 Nuts for General Applications: Machine Screw Nuts; and Hex, Square, Hex Flange, and Coupling Nuts

　　ASME B18.6.9-2010 (R2017) Wing Nuts

　　ASME B18.16.4-2008 Serrated Hex Flange Locknuts 90,000 psi

　　ASME B18.16.6-2017 (R2022) Prevailing Torque Locknuts

　　MATERIAL AND PHYSICAL

　　SAE J995-2017 Mechanical and Material Requirements for Steel Nuts

　　ASTM A194/A194M-2023 Carbon Steel, Alloy Steel, and Stainless Steel Nuts for Bolts for High Pressure or High Temperature Service, or Both

　　ASTM A563-2023 Carbon and Alloy Steel Nuts

　　ASTM F467-2013 (R2018) Nonferrous Nuts for General Use

　　ASTM F594-2022 Stainless Steel Nuts

　　IFI-101 2002 (R2013) Torque-Tension Requirements for Prevailing-Torque Type Steel Hex and Hex Flange Nuts

　　IFI-155-2005 (R2013) Test Procedure for the Performance of Nonmetallic Resistant Element Prevailing-Torque Nuts

　　IFI-160-2007 (R2013) Test Procedure for the Performance of Nuts with Pre-Applied Adhesive Coated Threads

　　SCREW SECTION

　　ASME B18.6.1-1981 (R2016) Wood Screws

　　ASME B18.6.2-2020 Square Head Set Screws and Slotted Headless Set Screws

　　ASME B18.6.3-2023 Machine Screws, Tapping Screws, and Metallic Drive Screws

　　ASME B18.6.8-2010 (R2017) Thumb Screws and Wing Screws

　　ASME B18.13-2017 (R2022) Screw and Washer Assemblies – SEMS

　　IFI-113-2015 Steel Self-Drilling Tapping Screws

　　ASTM C954-2022 Steel Drill Screws for the Application of Gypsum Panel Products or Metal Plaster Bases to Steel Studs from 0.033 in. (0.84 mm) to 0.112 in. (2.84 mm) in Thickness

　　ASTM C1002-2022 Steel Self-Piercing Tapping Screws for the Application of Gypsum Panel Products or Metal Plaster Bases to Wood Studs or Steel Studs

　　ASTM C1513-2018 Steel Tapping Screws for Cold-Formed Steel Framing Connections

　　WASHER SECTION

　　ASME B18.21.1-2009 (R2016) Washers: Helical Spring-Lock, Tooth Lock, and Plain Washers

　　ASTM F436/F436M-2019 Hardened Steel Washers Inch and Metric Dimensions

　　ASTM F2437/F2437M-2017 (R2023) Carbon and Alloy Steel Compressible-Washer-Type Direct Tension Indicators for Use with Cap Screws, Bolts, Anchors, and Studs

　　RIVET SECTION

　　ASME B18.1.1-1972 (R2021) Small Solid Rivets 7/16 In. Nominal Diameter and Smaller

　　ASME B18.1.2-1972 (R2021) Large Rivets 1/2 In. Nominal Diameter and Larger

　　ASME B18.7-2007 (R2017) General Purpose Semi-Tubular Rivets, Full Tabular Rivets, Split Rivets, and End Caps

　　IFI-110-2003 (R2013) Glossary of Terms Relating to Blind Rivets

　　IFI-114-2015 Break Mandrel Blind Rivets

　　IFI-116-2015 Multi-Grip Break Mandrel Blind Rivets

　　IFI-117-2003 (R2013) Pull Through Mandrel Blind Rivets

　　IFI-119-2003 (R2013) Structural Flush Break Pull Mandrel Self-Plugging Blind Rivets

　　IFI-123-2003 (R2013) Drive Pin Blind Rivets

　　IFI-126-2003 (R2013) Break Mandrel Closed End Blind Rivets

　　IFI-130-2003 (R2013) Structural Splitting Self-Plugging Pull Mandrel Blind Rivets

　　IFI-134-2015 Structural Positive Locking, Self-Plugging Blind Rivets

　　IFI-135-2013 Mechanical Testing of Blind Rivets

　　IFI-137-2003 (R2013) Inspection and Quality Assurance for General Purpose Blind Rivets

　　PIN SECTION

　　ASME B18.8.1-2014 (R2019) Clevis Pins and Cotter Pins (Inch Series)

　　ASME B18.8.2-2020 Taper Pins, Dowel Pins, Straight Pins, Grooved Pins and Spring Pins (Inch Series)

　　COATINGS AND FINISHES SECTION

　　ASTM B695-2021 Coatings of Zinc Mechanically Deposited on Iron and Steel

　　ASTM F1941/F1941M-2016 Electrodeposited Coatings on Mechanical Fasteners, Inch and Metric

　　ASTM F2329/F2329M-2015 (R2023) Zinc Coating, Hot-Dip, Requirements for Application to Carbon and Alloy Steel Bolts, Screws, Washers, Nuts and Special Threaded Fasteners

　　ASTM F3393-2020e1 Zinc-Flake Coating Systems for Fasteners

　　QUALITY SECTION

　　ASME B18.2.9-2010 (R2021) Straightness Gage and Gaging for Bolts and Screws

　　ASME B18.18-2017 (R2021) Quality Assurance for Fasteners

　　ASTM A370-2023 Standard Test Methods and Definitions for Mechanical Testing of Steel Products

　　ASTM F606/F606M-2021 Test Methods for Determining the Mechanical Properties of Externally and Internally Threaded Fasteners, Washers, Direct Tension Indicators, and Rivets

　　ASTM F788-2020ε1 Surface Discontinuities of Bolts, Screws, and Studs, Inch and Metric Series

　　ASTM F812-2012 (R2022)ε1 Surface Discontinuities of Nuts, Inch and Metric Series

　　ASTM F1470-2024 Standard Practice for Fastener Sampling for Specified Mechanical Properties and Performance Inspection

　　ASTM F2282-2023 Quality Assurance Requirements for Carbon and Alloy Steel Wire, Rods, and Bars for Mechanical Fasteners

　　ASTM F2328-2017 (R2022) Determining Decarburization and Carburization in Hardened and Tempered Threaded Steel Bolts, Screws, Studs, and Nuts

　　IFI-124-2002 (R2013) Test Procedure for the Performance of Nonmetallic Resistant Element Prevailing-Torque Screws

　　IFI-125-2007 (R2013) Test Procedure for the Performance of Adhesive Coated Prevailing-Torque Screws

　　IFI-143-2002 (R2013) Test for Evaluating the Torque-Tension Relationship on Both Externally and Internally Threaded Fasteners

　　GRADE MARKS SECTION

　　REFERENCE SECTION

　　INDEX
